Function and Introduction
1.Bu used to production after curing line.
2.It helps to turn over the modules from front to back after frame fixed.
3.Reduce labor cost.
Main Parameter
Module Format：Length(1580-2000)mm×Width(800-1000)mm
Cycle time：＜25s
Max Capacity：＞1200/day
Online Operator：none
Weight：around 1200kg
Rated power(kw)：4.0KW
Pressure(MPa)：0.6MPa
Dimension(LXWXH)：2700mmx1450mmx1815mm
Environmental requirement：temperaure18-30℃.Humidity ＜75%.
Advantage
1.The machine is made by steel welding with high strength and stable transmission.
2.It is better to avoid touch between people and machine, reduce risk of crack of module.
3.Labor intensity come down, keep production speed and efficiency.
|
