Solar Panels Production Line Glass Unloader

Glass unloader

The suction cup is used to absorb the second-floor glass of the double wave component after the sheet to repair

♦ Applicable components: conventional, half sheet and double glass components in length 1640-2500mm & width 950-1400mm
♦ Worki ng beat: 22 seconds
♦ Maximum production capacity: 3,400 pcs / day
♦ Online operator: 0
♦ Rated power (KW): 3KW
♦ Gas consumption (L/min): 60 L/min
♦ Pressure (M Pa):0.6-0.BM Pa
♦ Interface specification: 12
♦ Overall dimension 3650mm*3300mm*2900mm
♦ weight:1640KG

1. Choose servo motor for high transfer accuracy and stable transmi ssion performance;
2. Advanced design principles and processing methods to ensure the reliability of the whole machine operation;
3. Automatic whole-process control to avoid personnel intervention and high production efficiency;
4. The whole machine is equipped with a safety fence, which has the safety protection function;
5. Computer programming and control, highly intelligent, simple and easy to operate;
6. Convenient installation, energy saving and environmental protection, easy to maintain, and low price;
