Function and Introduction
Complete automatic gumming action.
1.Operator put the aluminum frame being placed on the dispensing table first, then machine carry on automatic dispensing.
2.There are several pneumatic components be used cooperatively ,which is efficiency and convenient
3.Serve motor control the machine precisely.
Main parameter
Module Format：L(1580-2000)mm × W(800-1000)mm
Operator online：one
Weight：around 900kg
Rated power(kw)：1.41kw
Pressure(MPa)：0.6-0.8MPa
Connection format：Φ12
Noise (dbA)：＜72db
Dimension(LXWXH)：2580mmx1080mmx1880mm
Advantage
1. The aluminum frame are placed to the dispensing table manually. Dispensing table moves and the machine dispenses automatically in a stable running.
2. The dispensing system can run stably and dispense uniformly.
3. The machine uses pinion and rack transmission mechanism driven by servo motor, and guided by linear rail, with advantages such as precise positioning and stable running
4. User-friendly interface for operating and programming.
|
