Solar Panel Module Production Line Assembly Line

Cell Stringing & Lay-Up

Tabber-Stringer Machine: Solder and interconnect cells into precise strings.

Automated Lay-Up Table: Places cell strings, EVA sheets, and backsheet with exact alignment.

Pre-Lamination Inspection

Infrared Pre-Check: Verifies cell integrity-detecting micro-cracks early.

Alignment Verification: Camera-guided checks ensure uniform spacing.

Vacuum Laminator

Dual-Chamber Oven: Sequentially heats and evacuates air, encapsulating cells in EVA/POE.

Programmable Heat & Pressure: Profiles tailored to your encapsulant and climate.

Edge Trimming & Framing

High-Precision Trimming Machine: Cleans excess encapsulant for flush edges.

Automated Framing Station: Installs anodized aluminum frames with torque-controlled fastening.

EL Detection & Final Inspection

Electroluminescence Station: In-line darkroom captures IR images, identifying hidden cell faults.

Load Testing & IV Curve Tracer: Confirms electrical performance against specifications.

Packing & Palletizing

Automatic Stacker: Neatly arranges finished modules.

Robotic Palletizer: Wraps and secures pallets for shipping.







Modular Design: Expand capacity by adding parallel sub-lines; fits any factory footprint.
High Throughput: Up to 1,200 panels/hour, supporting both standard and large-format modules.
Advanced Quality Control: Multi-point checks (IR, optical, electrical) ensure <0.5% defect rate.
Smart Factory Integration: PLC-driven synchronization, data logging, and Industry 4.0 connectivity.
Energy-Efficient Operation: Optimized heating zones and vacuum pumps minimize power consumption.
User-Friendly HMI: Central touchscreen interface for recipe management, diagnostics, and remote support.
